Information Valid for PED model as for MED one:
Approved / Certified by:
![Certified](/sites/default/files/inline-images/certified__5.JPG)
Fire Rating: 55 A 233 B C
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-c-.jpg)
- 12 Kg powder fire extinguisher, auxiliary pressure, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7 (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10. Quality Product certification guaranteed by Bureau Veritas Italia.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.
Characteristics:
- Cylinder: In high-strength alloy steel, 3 pieces drawing, with clip, external powder painting Red Ral 3000.
- Extinguishing Agent: ABC Powder - MAP 20%.
- Propellant: Auxiliary pressure. Fire extinguisher pressurized at moment of use with 225g CO2 cartridge.
- Valve: M. 74x2, lightweight aluminum alloy, activation with percussion method.
- Use: A B C fire rating (solid materials, flammable liquids, flammable gas).
- Bracket: Wall-mounted bracket for fire extinguisher with clip, red painting, in standard equipment
Technical Specifications:
- Fire Rating: 55 A 233 B C
- Extinguishing Agent: ABC powder - MAP 20 % - EPW 18462 (ABC Favorit Tertia - Rühl
- Propellant: Cartridge with 225g CO2
- Temperature Range: -30°C /+60°C
- Nominal Charge: 12 Kg
- Full Weight: ~ 18,7 Kg
- Dimensions: Height 610 (valve) / 625 (hose) +/- 5 mm - Diameter (cylinder) 182 +/- 2 mm
- Discharge Time: ~ 30,9 sec.
- Max Valve Tightening: Minimum 40 Nm, Maximum 60 Nm
- Cylinder Pressure Test: PT 30 bar
- Cylinder Volume: 12,2 L.
- Safety Valve: Set 24 +/- 2 bar
- Cylinder Material: Alloy steel
- Treatment: Outside: Sandblast and powder painting, Ral 3000
