Information for both MED and PED models:
APPROVED/CERTIFIED FIRE EXTINGUISHER:
![estintore certificato](/sites/default/files/inline-images/estintore%20certificato_1.JPG)
Fire class: 8 A 55 B 40 F
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-f-.jpg)
![Suitable on Polar Solvents](/sites/default/files/inline-images/suitable.JPG)
![Frost Resistance](/sites/default/files/inline-images/frost-resistance.JPG)
- 2 L. foam fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7 (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristics:
- Cylinder: Alloy steel, deep drawing epoxypolyestere powder painting Red Ral 3000.
- Exintinguishing Agent: Water foam.
- Propellant: Dehumified air or N2.
- Valve: M. 30x1.5, brass body levers with red painting Ral 3000.
- Use: A B F fire rating (solid materials, flammable liquidis, cooking olis).
- Bracket: Iron wire in standard equipment.
- Frost resistance up to -30°C
Suitable for use on Polar Solvents
Technical specifications:
- Fire Rating: 8 A 55 B 40 F
- Extinguishing agent : EW-30 foam
- Propellant : Dehumidified air or N2 ,15 Bar at 20°C
- Temperature range : -30°C +60°C
- Nominal charge : 2 L
- Full weight : ~ 3,7 Kg
- Dimensions :Height (base-valve): 365 mm - Diameter: 110 mm
- Discharge time: 16,5 sec.
- Valve tightening torque: Minimum 45 Nm, Maximum 68 Nm
- Cylinder pressure test : PT 27 Bar
- Cylinder volume: 2,4 L.
- Safety valve :Set between 20 and 26 bar
- Cylinder material : Alloy steel
- External/internal treatment : Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour/ Internal plastic lining
