Information for both PED and MED models:
Approved/Certified by:
![estintori certificati](/sites/default/files/inline-images/certificato_3.JPG)
Fire Class: 233 B
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-b.jpg)
20 Kg Carbon Dioxide CO2 Fire Extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 1866-1 (D.M. 6.3.92), certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1000 V, at a distance of 1 meter.
Characteristics:
- Cylinder: Alloy steel, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: Carbon Dioxide 99,99 % (CO2) .
- Valve: W 28.8, brass body, handwheel red painting, with protection for valve.
- Use: Fire Rating class B (flammable liquids).
- Bracket: Chassis on wheels, red painting Ral 3000.
Technical Specifications:
- Fire Rating: 233 B
- Extinguishing Agent: Carbon Dioxide 99,99 % (CO2)
- Temperature Range: -30°C / +60°C
- Nominal Charge: 20 Kg
- Full Weight : ~ 64 kg
- FRAME WEIGHT: ~ 8,20 Kg (with wheels)
- Dimensions: Height 1100 +/- 10 mm Width 485 +/- 10 mm - Depth (max size) 440 +/- 10 mm
- Discharge Time: ~ 18,4 seconds
