APPROVED/CERTIFIED FIRE EXTINGUISHER:
![100 L. water + additive Wheeled Fire Extinguisher - UNI EN 1866-1 - Model: 19118-52 - MED 2014/90/EU - PED 2014/68/UE](/sites/default/files/inline-images/cert-19508_0.jpg)
FIRE RATING: A IV B
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b.jpg)
- 50 L. water + additive wheeled fire extinguisher, temperature range from +5°C to +60°C, manufactured in accordance to EN 1866-1 (D.M. 6.3.92), approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Caratteristiche:
- CYLINDER: Stainless steel AISI 304, epoxypolyestere powder painting, Red Ral 3000.
- EXTINGUISHING AGENT: Water based foam.
- PROPELLANT: Dehumidified air or Nitrogen (N2 ).
- VALVE: 2”-F , brass body, lever with green painting Ral 6029.
- USE: A B fire rating (solid materials, flammable liquids).
- BRACKET: Chassis on wheels, welded at the cylinder, red painting Ral 3000.
TECHNICAL SPECIFICATIONS:
- FIRE RATING: A IV B
- EXTINGUISHING AGENT: Water based foam (2 % SC-6 orchidee + 98 % Water) (* Hyper-filtered water with an osmosis process)
- PROPELLANT: Dehumidified air or Nitrogen (N2 ), 15 Bar at 20°C
- TEMPERATURE RANGE: +5°C +60°C
- NOMINAL CHARGE: 50 Liters
- FULL WEIGHT: ~ 76,5 kg
- DIMENSIONS: Height 1100 +/- 10 mm ; Width 490 +/- 10 mm - Depth 500 +/- 15 mm
- DISCHARGE TIME: ~ 52,3 seconds
