Information for both Med and PED models:
Approved / Certified by:
![](/sites/default/files/users/emmeadmin/estintore-certificato-3.jpg)
Fire Class: 34 A 233 B
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b.jpg)
-6 L. foam fire extinguisher, pressurized at moment of use, temperature range from +5°C to +60°C, manufactured in accordance to EN 3-7:2008, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
-Quality Product certification guaranteed by Bureau Veritas Italia.
-Suitable for use on fire involving electrical voltages up to 35.000 V, at a distance of 1 mt.
Characteristics:
• CYLINDER Alloy steel, deep drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.
• EXTINGUISHING AGENT Water foam.
• PROPELLANT Fire extinguisher pressurized at moment of use with gr.55 CO2 cartridge.
• VALVE M. 74x2, lightweight aluminum alloy, activation with percussion method.
• USE A B fire rating (solid materials, flammable liquids).
• BRACKET Wall-mounted bracket for fire extinguisher with clip, red painting, in standard equipment.
Technical Specifications:
FIRE RATING 34A 233 B
EXTINGUISHING AGENT EWAB15 foam (1,5 % SC 6 + 7 % Inilam AX + 91,5 % Water)
PROPELLANT Internal cartridge with gr. 55 CO2
TEMPERATURE RANGE +5°C / +60°C
NOMINAL CHARGE 6 L.
FULL WEIGHT ~ 11,1 Kg
DIMENSIONS Height 520 mm Diameter 160 mm
DISCHARGE TIME 35 sec.
VALVE TIGHTENING TORQUE Minimum 40 Nm, Maximum 60 Nm
CYLINDER PRESSURE TEST PT 27 bar
CYLINDER VOLUME 7,1 L.
SAFETY VALVE Set 24 +/- 2 bar
CYLINDER MATERIAL Alloy steel
EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour/Internal plastic lining
