TESTED SUCCESSFULLY ON LITHIUM BATTERY WITH CAPACITY:
36 V - 750 W/h - 20,1 Ah
APPROVED/CERTIFIED FIRE EXTINGUISHER:
![APPROVED/CERTIFIED FIRE EXTINGUISHER](/sites/default/files/inline-images/certificato_15.JPG)
FIRE RATING: 27 A 233 B 40 F
![Classe di fuoco Estintore per Batterie al Litio](/sites/default/files/inline-images/Classe-di-fuoco-Estintore-per-Batterie-al-Litio.jpg)
6 L foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to UNI EN 3-7, (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10. Certified by Benor. Quality Product certification guaranteed by Bureau Veritas Italia.
- DIELECTRIC Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.
- CYLINDER Stainless steel, 3 pieces drawing, external powder painting Red Ral 3000.
- EXTINGUISHING AGENT Lith-M 10. Water-based foam.
- PROPELLANT Dehumidified air or nitrogen (N2 ).
- VALVOLE M. 30x1.5, brass body, levers with green painting Ral 6029.
- USE: A B F fire rating (solid materials, flammable liquids, cooking oils).
TECHNICAL SPECIFICATIONS:
- FIRE RATING: 27 A 233 B 40 F
- EXTINGUISHING AGENT: Foam Lith-M 10
- PROPELLANT: Dehumidified air or Nitrogen (N2), 15 bar at 20°C
- TEMPERATURE RANGE: 0°C / +60°C
- NOMINAL CHARGE: 6 Liters
- FULL WEIGHT: ~ 8,75 Kg
- DIMENSIONS: Height (base - valve) 530 +/- 5 mm - Diameter (cylinder) 160 +/- 2 mm
- DISCHARGE TIME: ~ 43,5 seconds
Prerequisite when using the fire extinguisher on lithium batteries:
According to tests executed with this fire extinguisher, it's possible to stop the combustion of a lithium-ion battery with a water based fire extinguisher with foam additives. It has been verified that the use of the fire extinguisher allows to lower the temperature and control any re-ignitions of the cells present inside the battery (generated by the chain reaction of the same and due to their shape inside the battery pack). The battery tested has a voltage of 36 V with a capacity of 20.1 Ah and an anergy value of 750 W/h. The fire extinguisher tested is therefore effective in containing the flames emanated from a battery with same or inferior characteristics compared to the one tested.
*NOTE: the test was executed on a new battery and so at full efficiency.
SAFETY WARNING:
The combustion of lithium-ion batteries realeses very harmful gases and fumes. Direct exposure to high concentrations of gases emanating from the combustion of lithium-ion batteries can cause serious damage to health. Lithium-ion batteries can have unpredictable phenomenons during fire, such as explosive reactions caused by the pressure of the cells inside the battery pack. it's advisable to use appropriate safety devices. The use of fire extinguisher is recommended for professional and expert staff. The use of fire extinguisher by uninformed people can lead to lower results and cause damage to involved people.
USE ON BATTERIES FIRES:
- Follow the operating Instructions printed on the main fire extinguisher label
- In case of use of the fire extinguisher on fires from lithium-ion batteries, it's advisable to keep the security gap during dispensing
- Do not expose yourself directly to the flames during dispensing.
- Dispense the extinguishing with regular intervals. Do not dispense it in a single intervention.
- Let the extinguishing penetrate inside the casing containing the battery pack.
- This fire extinguisher is a pressure container and must not be drilled, dented or submitted to external alterations.
- Don't aim the jet at people.
