Approved / Certified by:
![Approved / Certified](/sites/default/files/inline-images/benor2_1.JPG)
Fire rating: 27 A 233 B 40 F
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-f-.jpg)
- 6 L foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to UNI EN 3-7 (D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10. Certified by Benor.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 meter.
Characteristics:
- Cylinder: Stainless steel, 3 pieces drawing, external powder painting Red Ral 3000.
- Extinguishing Agent: Water-based foam.
- Propellant: Dehumidified air or nitrogen (N2).
- Valve: CPF M. 30x1.5, brass body, with anti-corrosion treatment.
- Use: A B F fire rating (solid materials, flammable liquids, coocking oil).
Technical Specifications:
- Fire Rating: 27 A 233 B 40 F
- Extinguishing Agent: Foam EWAB15 (2 % SC-6 + 10 % Inilam AX + 88 % Water)
- Propellant: Dehumidified air or Nitrogen (N2), 15 bar at 20°C
- Temperature Range: 0°C / +60°C
- Nominal Charge: 6 L
- Full Weight: ~ 8,8 Kg
- Dimensions: Height (base - valve) 530 +/- 5 mm - Diameter (cylinder) 160 +/- 2 mm
- Discharge Time: ~ 43,5 seconds
