Approved / Certified:
![22064-40](/sites/default/files/inline-images/22064-40.JPG)
Fire Rating: 43 A 233 B 40 F
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-f-.jpg)
-6 L. foam fire extinguisher, temperature range from +5°C to +60°C, manufactured in accordance to EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
-Quality Product certification guaranteed by Bureau Veritas Italia.
-Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristicss:
- Cylinder: Stainless steel AISI 304, 3 pieces drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: water foam.
- Propellant: Dehumidified air or N2.
- Valve: M. 58x2, lightweight aluminium alloy AA6061 body, with external check valve, levers with black painting.
- Use: A B F fire rating (solid materials, flammable liquids, coocking oil).
Technical Specifications:
- Fire Rating: 43 A 233 B 40 F
- Extinguishing Agent: Foam EWAB1 (2 % SC-6 + 10 % Inilam AX + 88 % Water)
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: -5°C / +60°C
- Nominal Charge: 6 Liters
- Full Weight: ~ 8,7 Kg
- Dimensions: Height (base - valve) 550 +/- 5 mm - Diameter (cylinder) 160 +/- 2 mm
- Discharge Time: ~ 29,0 seconds
