Approved and Certified by:
![Estintore certificato](/sites/default/files/inline-images/estintore-certificato.JPG)
Fire class: 13 A
![Classe di fuoco A](/sites/default/files/inline-images/classe-di-fuoco-a_.jpg)
-6 L. water fire extinguisher, temperature range from +5°C to +60°C, manufactured in accordance to EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU.
-Quality Product certification guaranteed by Bureau Veritas Italia.
-Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristics:
- Cylinder: Stainless steel AISI 304, 3 pieces drawing, with clip, polished.
- Extinguishing Agent: Water.
- Propellant: Dehumidified air or N2.
- Valve:M. 58x2, lightweight aluminum alloy AA6061 body, with external check valve, black painting.
- Use: A fire rating (solid materials)..
- Bracket: Wall-mounted for valve, in standard equipment.
Technical Specifications:
- Fire Rating: 13 A
- Extinguishing Agent: Water
- Propellant: Dehumidified air or N2 ,15 Bar a 20°C
- Temperature Ranged: 5°C +60°C
- Nominal Charge: 6 L
- Full Weight: ~ 8,8 kg
- Dimensions Height: 560 mm - Diameter: 160 mm
- Discharge Time: 21 sec.
- Valve Tightening Torque: Minumum 40 Nm, Maximum 60 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 7,8 L.
- Safety Valve:Set between 22 and 27 bar
- Cylinder Material: Stainless steel AISI 304
- External/Internal Treatment: Polishing
