APPROVED/CERTIFIED:
![estintore carrellato certificato](/sites/default/files/inline-images/certificato-med.jpg)
FIRE RATING: A IV B C
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-c.jpg)
- 50 kg powder wheeled fire extinguisher, pressurized at moment of use , temperature range from -30°C to +60°C, manufactured in accordance to EN 1866-1, approved to European Marine Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristics:
CYLINDER Alloy steel, epoxypolyestere powder painting, Red Ral 3000.
EXTINGUISHING AGENT ABC Powder - MAP 40 %.
PROPELLANT Fire extinguisher pressurized at moment of use with CO2 external cylinder, complete of protection for valve.
CAP Brass body, 2”.
USE A B C fire rating (solid materials, flammable liquids, flammable gas).
BRACKET Chassis on wheels, welded at the cylinder, red painting RAL3000.
TECHNICAL SPECIFICATIONS:
- FIRE RATING: A IV B C
- EXTINGUISHING AGENT: EPB 0351 (QFIRE-40) - ABC Powder - MAP 40 %
- PROPELLANT: 1,2 Kg di CO2
- TEMPERATURE RANGE: -30°C /+60°C
- NOMINAL CHARGE: 50 Kg
- FULL WEIGHT: ~ 85 kg
- DIMENSIONS: Height 1100 +/-5 mm - Width 490 +/-5 mm - Depth 560 +/-5 mm
- DISCHARGE TIME: ~ 50 sec.
- CAP TIGHTENING TORQUE: Minimo 60 Nm, Massimo 70 Nm
- CYLINDER PRESSURE TEST: PT 30 bar
- CYLINDER VOLUME: 62 L.
- SAFETY DEVICE: Set between 21 and 26 bar
- CYLINDER MATERIAL: Alloy steel
- EXTERNAL/INTERNAL TREATMENT: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
