150 Kg Dry Powder Wheeled Fire Extinguisher - A IV B C - MED 2014/90/EU - Code 16158-52
150 Kg Dry Powder Wheeled Fire Extinguisher - A IV B C - MED 2014/90/EU - Code 16158-52

150 Kg Dry Powder Wheeled Fire Extinguisher - A IV B C - MED 2014/90/EU - Code 16158-52

Code
16158-52
Data Sheet
MED Certificate 2014/90/EU

150kg powder wheeled fire extinguisher, pressurized at moment of use , temperature range from -30°C to +60°C, manufactured in accordance to EN 1866-1, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.

150 Kg Dry Powder Wheeled Fire Extinguisher - A IV B C - MED 2014/90/EU - Code 16158-52

Information for both PED and MED models

Approved/ Certified by :

certificato estintore 2

Fire rating : A IV B C

classe di fuoco a b c

- 150kg powder wheeled fire extinguisher, pressurized at moment of use , temperature range from -30°C to +60°C, manufactured in accordance to EN 1866-1, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.

- Quality Product certification guaranteed by Bureau Veritas Italia.

- Suitable for use on fire involving electrical voltages up to 1000 V, minimum distance of 1 mt

Charcateristics :

  • CYLINDER Alloy steel, epoxypolyestere powder painting, Red Ral 3000.
  • EXTINGUISHING AGENT ABC powder - MAP 40 %
  • PROPELLANT Fire extinguisher pressurized at moment of use with 5kg Co2 external cylinder, complete of protection for valve.
  • CAP Brass 2”.
  • USE A B C fire rating (solid materials, flammable liquids, flammable gas).
  • BRACKET Chassis on wheels, welded at the cylinder, red painting RAL3000.

Technical specifications :

  • FIRE RATING A IV B C
  • EXTINGUISHING AGENT EPB 0351 (Q-Fire 40) Powder MAP 40 %
  • PROPELLANT External cylinder 5kg Co2
  • TEMPERATURE RANGE -30°C +60°C
  • NOMINAL CHARGE 150 Kg
  • FULL WEIGHT ~ 210 Kg
  • DIMENSIONS Height 1350 mm Width 750 mm Depth 640 mm
  • DISCHARGE TIME 90 sec.
  • CAP TIGHTENING TORQUE Minimum 60 Nm - Maximum 70 Nm
  • CYLINDER PRESSURE TEST PT 30 bar
  • CYLINDER VOLUME 170 L. SAFETY VALVE Set 20 and 21 bar
  • CYLINDER MATERIAL Alloy steel
  • EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour

Technical specifications :

  • FIRE RATING A IV B C
  • EXTINGUISHING AGENT EPB 0351 (Q-Fire 40) Powder MAP 40 %
  • PROPELLANT External cylinder 5kg Co2
  • TEMPERATURE RANGE -30°C +60°C
  • NOMINAL CHARGE 150 Kg
  • FULL WEIGHT ~ 210 Kg
  • DIMENSIONS Height 1350 mm Width 750 mm Depth 640 mm
  • DISCHARGE TIME 90 sec.
  • CAP TIGHTENING TORQUE Minimum 60 Nm - Maximum 70 Nm
  • CYLINDER PRESSURE TEST PT 30 bar
  • CYLINDER VOLUME 170 L. SAFETY VALVE Set 20 and 21 bar
  • CYLINDER MATERIAL Alloy steel
  • EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
