APPROVED/CERTIFIED:
![estintore carrellato certificato](/sites/default/files/inline-images/cert_3.JPG)
FIRE RATING: A B1 C
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-c.jpg)
- 30 Kg powder wheeled fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI 9492 (D.M. 6.3.92), certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.
Characteristics:
CYLINDER In high-strength alloy steel, external powder painting Red Ral 3000.
EXTINGUISHING AGENT ABC Powder - MAP 20 %.
PROPELLANT Dehumidified air or nitrogen (N2) .
VALVE 2”-F , brass body, lever with red painting Ral 3000.
USE A B C fire rating (solid materials, flammable liquids, flammable gas).
BRACKET Chassis on wheels, red painting Ral 3000.
TECHNICAL SPECIFICATIONS:
- FIRE RATING: A B1 C
- EXTINGUISHING AGENT: ABC Powder - MAP 20 % (Pro-Twenty - ProPhos Chemicals S.r.l)
- PROPELLANT: Dehumidified air or Nitrogen (N2), 15 bar at 20°C
- TEMPERATURE RANGE: -30°C /+60°C
- NOMINAL CHARGE: 30 Kg
- FULL WEIGHT: ~ 57 Kg
- DIMENSIONS: Height 1100 +/-10 mm - Width 460 +/-10 mm - Depth 445 +/-10 mm
- DISCHARGE TIME: ~ 64,5 seconds
