6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7
6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7

6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7

Data Sheet
PED Certificate 2014/68/UE

6 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU.

6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7

6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7

Approved/ Certified by:

6 Kg Powder Fire Extinguisher- Code 21064-51- 43A 233B C- EN 3-7

FIRE CLASS: 43 A 233 B C

Fire rating A B C

6 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU.


-Quality Product certification guaranteed by Bureau Veritas Italia.

-Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt.

Characteristics:

• CYLINDER Alloy steel, 3 pieces drawing, with clip, epoxypolyestere powder painting, Red Ral 3000.
• EXTINGUISHING AGENT ABC Powder - MAP 20 %.
• PROPELLANT Dehumidified air or N2 .
• VALVE M. 30x1.5, lightweight aluminum alloy AA6061 body, levers with red painting Ral 3000.
• USE A B C fire rating (solid materials, flammable liquids, flammable gas).

clip

Technical Specifications:

  • FIRE RATING 43 A 233 B C
  • EXTINGUISHING AGENT EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
  • PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
  • TEMPERATURE RANGE -30°C / +60°C
  • NOMINAL CHARGE 6 Kg
  • FULL WEIGHT ~ 9,5 Kg
  • DIMENSIONS Height 510 mm Diameter 160 mm
  • DISCHARGE TIME 18,5 sec.
  • VALVE TIGHTENING TORQUE Minimum 35 Nm, Maximum 55 Nm
  • CYLINDER PRESSURE TEST PT 27 bar
  • CYLINDER VOLUME 7,3 L.
  • SAFETY VALVE Set between 22 and 27 bar
  • CYLINDER MATERIAL Alloy steel
  • EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour

Technical Specifications:

  • FIRE RATING 43 A 233 B C
  • EXTINGUISHING AGENT EPW 18462 (ABC Favorit Tertia) ABC powder - MAP 20 %
  • PROPELLANT Dehumidified air or N2 ,15 Bar at 20°C
  • TEMPERATURE RANGE -30°C / +60°C
  • NOMINAL CHARGE 6 Kg
  • FULL WEIGHT ~ 9,5 Kg
  • DIMENSIONS Height 510 mm Diameter 160 mm
  • DISCHARGE TIME 18,5 sec.
  • VALVE TIGHTENING TORQUE Minimum 35 Nm, Maximum 55 Nm
  • CYLINDER PRESSURE TEST PT 27 bar
  • CYLINDER VOLUME 7,3 L.
  • SAFETY VALVE Set between 22 and 27 bar
  • CYLINDER MATERIAL Alloy steel
  • EXTERNAL/INTERNAL TREATMENT Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
