6 L Foam Portable fire extinguisher - PED EN 3-7 - Model: 22064-1
Approved / Certified:
Fire Rating: 43Â A 233Â B 75Â F
6 L. foam fire extinguisher, temperature range from +5°C to +60°C, manufactured in accordance to EN 3-7, certified according to the directive for pressure equipment PED 2014/68/EU.
Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 1.000 V, at a distance of 1 mt..
Features:
- Cylinder:Â Stainless steel AISI 304, 3 pieces drawing, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent:Â Water foam.
- Propellant: Dehumidified air or N2.
- Valve: CPF M 30X1.5, brass body, with anti-corrosion treatment.Â
- Use: A B F fire rating (solid materials, flammable liquids, coocking oil).
- Bracket: Wall-mounted for valve, in standard equipment.
Â
Technical Specifications:
- Fire Rating: 43 A 233Â B 75Â F
- Extinguishing Agent: EWAB1Â foam
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: +5°C +60°C
- Nominal Charge: 6 L
- Full Weight: ~ 8,4Â Kg
- Dimensions: Height  535 mm, Diameter 160 mm
- Discharge Time:Â 21Â sec.
- Max Valve Tightening: Between 45 and 68 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 7,8Â L.
- Safety Valve: Set 20 and 26 bar
- Cylinder Material: Stainless steel AISI 304
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour.
