APPROVED/CERTIFIED FIRE EXTINGUISHER:
![Certificato](/sites/default/files/inline-images/cert_26.JPG)
Fire Class: 21 A 183 B 40 F
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-a-b-f-.jpg)
9 L foam fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7, approved Marine Equipment Directive MED 2014/90/EU certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages up to 1.000 V, at a minimum distance of 1 meter.
Characteristics:
- CYLINDER: In high-strength alloy steel, with clip 3 pieces drawing, external powder painting Red Ral 3000.
- EXTINGUISHING AGENT: Water-based foam.
- PROPELLANT: Dehumidified air or nitrogen (N2).
- VALVE: CPF M. 30x1.5, brass body, with anti-corrosion treatment.
- USE: A B F fire rating (solid materials, flammable liquids, cooking oils).
Technical Specifications:
- FIRE RATING: 21 A 183 B 40 F
- EXTINGUISHING AGENT: EW-30 foam (100 % Premix MG6 -30)
- PROPELLANT: Dehumidified air or Nitrogen (N2), 15 bar at 20°C
- TEMPERATURE RANGE: -30°C / +60°C
- NOMINAL CHARGE: 9 Liters
- FULL WEIGHT: ~ 15,15 Kg
- DIMENSIONS: Height (base - valve) 635 +/- 5 mm - Diameter (cylinder) 170 +/- 2 mm
- DISCHARGE TIME: ~ 34,8 seconds
- VALVE TIGHTENING TORQUE: Minimum 45 Nm, Maximum 68 Nm
- CYLINDER PRESSURE TEST: PT 27 bar
- CYLINDER VOLUME: 10,7 L.
- SAFETY VALVE: Set between 20 and 24 bar
- CYLINDER MATERIAL: Alloy steel
- EXTERNAL/INTERNAL TREATMENT: Outside: Sandblast and powder painting, Ral 3000 - Inside: Plastic coating
