9 L Foam Portable fire extinguisher - PED En 3-7 - Model: 22094
Information for both PED and MED models:
Â
APPROVED/CERTIFIED BY:
Â
FIRE CLASS :Â 43Â A -Â 233Â B - 40Â F
Â
Â
-9 L. foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to EN 3-7:2008, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.
Â
-Quality Product certification guaranteed by Bureau Veritas Italia.
Â
-Suitable for use on fire involving electrical voltages up to 35.000 V, at a distance of 1 mt.
Â
Â
Characteristics:
- Cylinder:Â Alloy steel, 3 pieces drawing, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: water foam.
- Propellant: Dehumidified air or N2.
- Valve: M 30X1.5, brass body, levers with red painting RAL3000.
- Use: A B F fire rating (solid materials, flammable liquids, coocking oil).
- Bracket:Â Wall- mounted for valve, in standard equipment.
Technical Specifications :
- Fire Rating:Â 43Â A 233Â B 40 F
- Extinguishing Agent:Â EWAB15 foam
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: 0°C +60°C
- Nominal Charge:Â 9Â L
- Full Weight: ~ 14Â Kg
- Dimensions: Height  365 mm, Diameter 110 mm
- Discharge Time: 62 sec.
- Valve Tightening Torque:Â Minimum 45 Nm, Maximum 68 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume:Â 10,7Â L.
- Safety Valve: Set 20 and 26 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour /Â Internal plastic lining
