Information Valid for PED model as for MED one:
- 3 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7, approved to European Marine Directive MED 2014/90/EU, S.O.L.A.S. (Safety of life at sea) ‘74 (2000), certified according to the directive for pressure equipment PED 2014/68/EU.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving voltages of up to 1000 volts.
Features:
- Cylinder: Deep drawing alloy steel, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: ABC powder.
- Propellant: Dehumidified air or N2.
- Valve: Brass M 30X1.5, levers with red painting RAL3000.
- Use: A B C fire rating (solid materials, flammable liquids, flammable gas).
- Bracket: Wall-mounted in standard equipment.
- Fire Rating: 13 A 113 B C
- Extinguishing Agent: EPW 18462 powder
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: -30°C +60°C
- Nominal Charge: 3 Kg
- Full Weight: ~ 5,4 Kg
- Dimensions: Height 470 mm, Diameter 130 mm
- Discharge Time: 15 sec.
- Max Valve Tightening: Between 40 and 50 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 4,3 L.
- Safety Valve: Set 20 and 26 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
