6L Foam Portable fire extinguisher - PED EN 3-7 - Model: 22066-2
Â
Approved / Certified:
Fire Rating: 27Â A 233Â B 40 F
6 L. foam fire extinguisher, temperature range from 0°C to +60°C, manufactured in accordance to EN 3-7:2008, certified according to the directive for pressure equipment PED 2014/68/EU.
Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 35.000 V, at a distance of 1 mt.
Features:
- Cylinder: Deep drawing alloy steel, with clip, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: Water foam.
- Propellant: Dehumidified air or N2.
- Valve: M 30X1.5, brass body, levers with red painting RAL3000.
- Use: A B F fire rating (solid materials, flammable liquids, cooking oils).
- Bracket: Wall-mounted for valve, in standard equipment.
-Â Clip detail:
Â
Technical Specifications:
- Fire Rating: 27 A 233 B 40 F
- Extinguishing Agent:Â EWAB15 foam.
- Propellant: Dehumidified air or N2, 15 Bar at 20°C
- Temperature Range: 0°C +60°C
- Nominal Charge: 6 L
- Full Weight: ~ 9,4Â Kg
- Dimensions: Height  540 mm, Diameter 160 mm
- Discharge Time: 43 sec.
- Valve Tightening Torque:Â Minimum 45 Nm, Maximum 68 Nm
- Cylinder Pressure Test: PT 27 bar
- Cylinder Volume: 7,5Â L.
- Safety Valve: Set 20 and 26 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour / Internal plastic lining
