Information Valid for PED model as for MED one:
Approved / Certified:
![](/sites/default/files/users/emmeadmin/certified_fire_extinguisher-7.jpg)
Fire Rating: 34 B
![](/sites/default/files/users/emmeadmin/classe-di-fuoco-b.jpg)
- 2 kg Co2 fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to EN 3-7, approved to European Marine Directive MED 2014/90/EU, certified according to the directive for pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
- Quality Product certification guaranteed by Bureau Veritas Italia.
- Suitable for use on fire involving electrical voltages of up to 1000 V, at a distance of 1 mt.
Characteristics:
- Cylinder: Alloy steel, epoxypolyestere powder painting, Red Ral 3000.
- Extinguishing Agent: Carbon Dioxide 99,99%
- Valve: CPF M 25X2, brass body, levers with red painting RAL 3000.
- Use: B fire rating (flammable liquids).
Technical Specifications:
- Fire Rating: 34 B
- Extinguishing Agent: Co2 99,99%
- Temperature Range: -30°C / +60°C
- Nominal Charge: 2 Kg
- Full Weight: ~ 6,5 Kg
- Dimensions: Height (base-valve) 570 mm, Diameter 104 mm
- Discharge Time: 7,5 sec.
- Valve Tightening Torque: Minimum 95 Nm, Maximum 130 Nm
- Cylinder Pressure Test: PT 250 bar
- Cylinder Volume: 3 L.
- Safety Valve: Set 195 +15/-23 bar
- Cylinder Material: Alloy steel
- External/Internal Treatment: Sandblast and epoxypolyestere powder painting, Red Ral 3000 colour
